Xilinx Zynq UltraScale+ MPSoC SOM FPGA Core Board XCZU5EV

XCZU5EV

  • Model

    M5EV
  • Email

    David.ding@alinx.com
  • Temperature class

    -40℃~85℃
  • Price

    $ 1140

Related


Xilinx Zynq UltraScale + MPSoC FPGA Core board(Stamp hole)

4 x ARM® Cortex-A53 , 2 x Cortex-R5 processor

Mali-400 MP2 GPU and 16nm finfet+ programmable logic are combined to form an H.264 / h.265 video codec, which can encode and decode 4kx2k (60fps) video

  • ·4GB DDR4

    PS 4GB DDR4

  • ·FLASH storage

    8GB EMMC FLASH、32MB QSPI FLASH


key Features



Product parameters

Main Parameters

Core board

M5EV

FPGA Chip

XCZU5EV-2SFVC784I

Speed Grades

-2

Working Temperature

Industrial Grade,-40°C~85°C

CPU kernel

4 x Cortex™-A53 | 2 x Cortex™-R5

CPU frequency

1.333GHz | 533MHz

GPU Graphic processing sheet

Mali™-400 MP2

High speed connection interface

PCIe Gen2 x1 , 1x USB3.0 , Sata 3.1 , DisplayPort 1x Tri-mode Gigabit Ethernet

Common connection interface

1x SD2.0, 1x JTAG

PS DDR4

4GB, 64bit

QSPI | EMMC Flash

32MB | 8GB

Logic Cells

256K

Flip-Flops

234K

LUTs

117K

Max. Distributed RAM

3.5Mb

Total Block RAM | UltraRAM

5.1Mb | 18.0Mb

Clock Management Tiles (CMTs)

4

DSP Slices

1248

Video Codec Unit

H.264/H.265

PS MI/Os

15

PL I/Os

102

PL HP I/Os

96

PL HD I/Os

6

Connection mode

Stamp hole


Functions and interfaces

RAM

4GB DDR4, 64bit

QSPI Flash

One piece of 256Mbit QSPI flash, which can be used as FPGA user data storage

EMMC Flash

8GB, used in zynq system, can be used as a large capacity storage device of the system

Crystal oscillator

One passive crystal oscillator is provided to PS system


Power Supply Parameters

Voltage Input

+5 V DC


Package List

FPGA SoM Board

1





Structure Size

Size Dimension

70mm x 50mm

Number of Layers

16-Layer PCB




Super Combination with Mali™-400 MP2 GPU, 64bit DDR4 RAM

Industiral Grade Chip Dual ARM Application Processor

4x  ARM Cortex-A53,1.3GHz;2x Cortex™-R5, 533MHz;PS 4GB DDR4


HD video concept design

H.264 / H.265 video codec

It can encode and decode 4kx2k (60fps) video at the same time


Get Started Quickly ,Shorten Learning and Development Time

Provide Documents to Study

Provide schematic diagram, PCB structure diagram (PDF), packaging, reference design, etc. to facilitate secondary development


The warranty period of all products sold is 12 months, of which FPGA chips and LCD screens are wearing parts and are not covered by the warranty. All accessories and gifts are not covered under warranty.
